Four Sides Nine Rows Drilling Machine
Max. Center Distance Between Holes: L*B=2500mm*672mm
Min. Center Distance Between Holes: L*B=300mm*32mm
Max. Processing Length: 2500mm
Min. Processing Length: 300mm
Plate Thickness: 8-50mm
Total Number Of Spindles: 198pcs
Qty. Of Vertical Drilling Rows on Top: 3
Single bit Max. Drilling Dia: 35mm
Multi bits Max. Drilling Dia: 13mm
Max. Drilling Depth: 50mm
Installation Dia. Of Drill Bit Shaft: 10mm
Knife Installation Length: 57mm / 70mm
Spindle Speed: 2840rpm
Qty. Of Horizontal Drilling Row on Left and Right: 2
Qty. Of Vertical Drilling Row On Bottom: 4
Air Pressure: 0.5-0.6mpa
Motor Voltage: 380V / 60Hz
Total Power: 25.1kw
Net Weight: About 2800kg
Overall Dimensions: 5000*2250*2200mm
Processing Speed: 13-16 pcs/min
